G689 is a heavy duty double action pneumatic-hydraulic riveter designed for installation of CherryLOCK® Wiredraw rivets. This tool is equipped with a custom mounting system only compatible with double action pulling heads (H681), but with proper adapters it can be used with other front or side eject pulling heads.
Air Pressure 90 psi (6,2 bar) min./110 psi (7,6 bar) max.
Stroke 1.475 inch (37,47 mm)
Pulling Force 3,800 lbs. (16,9 kN) @ 90 psi (6,2 bar)
Weight 12.85 lbs. (5,90 kg)
Noise Level 74.1 dB (A)
Vibration less than 2.5 m/s2
Air Consumption 0.50 SCF/cycle (14,2 L/cycle)
