Cordless Power Riveter Kit PT-4000-MIL-1

Code: PT-4000-MIL-1
PART #: PT-4000-MIL-1
NSN #: 5130-01-449-9225
  • Powerful
  • Installs 5/32″ and 3/16″ Blind Bolts
  • Ergonomically Balanced
  • Productive
  • Pulls Most All Blind Rivets Through 1/4″ diameter including CherryMax
  • Pulling Force: 4,000 lbs.
  • Stroke: 0.787 inches
  • Dimensions: 11-7/8″ H x 10-3/8″ L x 2-5/8″ W
  • Power Source (Battery): 3.2 Ah, 12 vdc Nickel-Metal (NiMH) Hydride Battery
  • Charger Source: 120 volt, 60 Hz or 220 volt, 50 Hz
  • Charger Cycle Time: One Hour
  • Operating Temp. Range (Ambient): 32 to 120 degree F
  • Housing Material: Impact resistant glass filled nylon
  • Metal Case Dimensions: 4-1/2″ H x 14″ L x 11-1/2″ W

Call for Price


PT-4000-MIL-1 Cordless Power Riveter Kit


The new, higher pull force PT-4000 Cordless Blind Riveter offers the sheetmetal technician the ability to install most all 1/4″ diameter blind rivets while retaining all the features of the PT-3000 with respect to size, weight and versatility.

The PT-4000-MIL-1 provides nosepieces and adapters for installing all most popular 3/16″ and 1/4″ diameter blind rivets for both Aerospace and Industrial applications.  Types of rivets installable with the PT-4000 include, but are not limited to, virtually all CherryMax® (M7885), Avdel or Cherry Monobolts®, and Pop® type rivets.  The PT-4000 is also capable of installing both 5/32″ and 3/16″ Blind bolts (MS90353/54-S/U) with the proper nosepieces.

Pulls most blind rivets through 3/16″ including CherryMAX. Uses existing CherryMAX tooling with included adapter. Lightweight & ergonomically balanced. No stem jamming. Positive stroke control. Includes 2 quick change batteries. Overload & operating tempe
